NWD604 Electric Hospital Bed

NWD604 Electric Hospital Bed

Short Description:






Product Detail

Features

Download

NWD604_s1

Design
Head and foot board can meet hospital requirements for infection control and enables daily disinfection

Plastic
Environmentally friendly plastic, non-toxic and odorless

NWD604_s2
NWD604_s3

Painting
The overall bed uses a series of processes: pickling, phosphating,washing, oxidation, automatic spraying line, using electrostatic spraying process, providing a bright color and strong attachment.

Weldingl
Aluminum alloy side rail, 6-staff, collapsed type with safe lock.

NWD604_s4
NWD604_s5

Electric Control System
Famous brand motor has passed UL medical certification, stable performance, and motor noise of 50dB.

Hand Controller
The hand controller equipped with a flexible spring cord, felicitating operation of bed in the optimal position and allowing the nurse to easily control all standard functions.

NWD604_s6
NWD604_s7

Platform
Bed surface width is 900mm, using four-piece bed platform, stamping forming platform, smooth surface no welding scar. With multi-air hole, it's breathable and has non-slip function. The surface has no welding scar, the back has steel reinforcement, adopts double support structure, prolongs the life of the bed, and the load-bearing capacity is 200KG.

Siderail
With angle indicator, beautiful appearance, easy to operate, durable, easy to clean, anti-pinch design, guardrail lifting using a damper device to control the speed and noise, can be hidden under the bed.

NWD604_s8
NWD604_s9

Head & Foot Board
Simple head and foot board, easy and quick disassembly. Foot board with name card.

Castors
Adopt diameter ≥125mm silent hardshell castors, each caster with brake.

NWD604_s10
NWD604_s11

Drainage Hook
Drainage hooks on both sides of the bed.

Manual CPR
Equipped with manual CPR emergency.
NWD604_s12

  • Previous:
  • Next:

  • Technical parameters

    External size (LxW)
    2160×1080(±10mm)
    Height adjustment
    470-820mm(±10mm)
    Mattress platform
    1930x900mm
    Back-rest adjustment
    0-75° (±10°)
    Knee-rest adjustment
    0-55° (±10°)
    Safe working load
     200 kg

    Technical configuration

    Linear motor
    3pcs
    5″ hardshell castors
    4pcs
    PP side rail extra height
    1set
    PP bed ends with safe lock
    1set
    Hand controller
    1pc
    lV Pole Prevision 4pcs
    Drainage hook
    2pcs
    Mattress holder 2pcs
    Manual CPR
